| Part No. | Stock Qty | 10+ | 100+ | 500+ | 1000+ | Qty |
|---|---|---|---|---|---|---|
|
3046-02
2x1 Positions |
1000 in stock | £0.46 | £0.38 | £0.31 | £0.26 | |
|
3046-04
2x2 Positions |
7 in stock | £0.49 | £0.42 | £0.35 | £0.29 | |
|
3046-06
2x3 Positions |
1000 in stock | £0.59 | £0.49 | £0.40 | £0.33 | |
|
3046-08
2x4 Positions |
1019 in stock | £0.52 | £0.43 | £0.34 | £0.30 | |
|
3046-10
2x5 Positions |
953 in stock | £0.62 | £0.52 | £0.42 | £0.34 | |
|
3046-12
2x6 Positions |
990 in stock | £0.68 | £0.57 | £0.44 | £0.37 | |
|
3046-14
2x7 Positions |
1000 in stock | £0.74 | £0.62 | £0.49 | £0.41 | |
|
3046-16
2x8 Positions |
10416 in stock | £0.86 | £0.77 | £0.69 | £0.56 | |
|
3046-18
2x9 Positions |
901 in stock | £0.98 | £0.80 | £0.68 | £0.54 | |
|
3046-20
2x10 Positions |
998 in stock | £0.99 | £0.82 | £0.67 | £0.56 | |
|
3046-22
2x11 Positions |
998 in stock | £1.12 | £0.92 | £0.74 | £0.62 | |
|
3046-24
2x12 Positions |
892 in stock | £1.22 | £1.02 | £0.81 | £0.68 |
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm pricing and delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
Insulator Material: Black Nylon 6T
Contact Material: Brass (square pin 0.624mm)
Contact Plating: Tin
Current Rating: 5 Amps(20 & 22awg), 4 Amps(24awg) (vs Wire Size - awg) 3 Amps(26awg), 2 Amps(22awg), 1Amp (30awg)
Rated Voltage: 250V AC(rms) or DC
DWV: 1500V AC for 1 minute
Contact Resistance: 10mΩ Max.
Operating Temperature: -25°C to +85°C
Tolerance: ±0.25mm
Glow-Wire Flammability: (GWFI) IEC 60695-2-12
Glow-Wire Ignition: (GWIT) IEC 60695-2-13
