Alternative Series ► MDC-3xx-R
| Part No. | Stock Qty | 100+ | 500+ | 1000+ | Qty |
|---|---|---|---|---|---|
|
KMDGX-3S-BS
100pcs Tray |
601 in stock | £1.02 | £0.94 | £0.87 | |
|
KMDGX-4S-BS
100pcs Tray |
1101 in stock | £0.99 | £0.92 | £0.85 | |
|
KMDGX-5S-BS
100pcs Tray |
Standard delivery 12 - 14 working days * |
£1.10 | £1.01 | £0.94 | |
|
KMDGX-6S-BS
100pcs Tray |
2016 in stock | £1.16 | £1.07 | £0.99 | |
|
KMDGX-8S-AS
100pcs Tray |
Standard delivery 12 - 14 working days * |
£1.74 | £1.61 | £1.49 | |
|
KMDGX-8S-BS
100pcs Tray |
Standard delivery 12 - 14 working days * |
£1.40 | £1.29 | £1.20 |
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm pricing and delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
Body PBT Thermoplastic, Black, Purple, or Green Color
Contacts Copper Alloy, Gold Plated
Insertion Force 4.5kg Max.
Extraction Force 0.4kg - 3.5kg
Durability 500 Cycles Min.
Rated Current 2A
Rated Voltage 12V DC
Insulation Resistance 500 Megohm Min. at 500V DC
Contact Resistance Before Durability Test Plug to Terminals: 30 milliohms Max. After Durability Test Plug to Terminals: 60 milliohms Max.
Dielectric Withstanding Voltage 500V RMS AC for 1 Minute
Operating Temperature -25°C to + 80°C
Product Features, PC99 colours available (subject to MOQ & materials), shielded options available for good conductivity, grounding and EMI/RFI protection.
