| Part No. | Stock Qty | Price Breaks | Qty | ||||
|---|---|---|---|---|---|---|---|
|
ESQ-103-59-G-D
3D CAD
2x3 positions |
Standard delivery 3 - 5 working days * |
1+: £1.59 | 50+: £1.54 | 100+: £1.46 | View all prices | ||
|
ESQ-104-59-L-D
3D CAD
2x4 positions |
Standard delivery 3 - 5 working days * |
1+: £1.62 | 50+: £1.58 | 100+: £1.50 | View all prices | ||
|
ESQ-109-59-G-D
3D CAD
2x9 positions |
Standard delivery 3 - 5 working days * |
1+: £3.19 | 25+: £3.10 | 50+: £2.94 | View all prices | ||
|
ESQ-112-59-G-D
3D CAD
2x12 positions |
Standard delivery 3 - 5 working days * |
1+: £4.25 | 10+: £4.13 | 25+: £3.92 | View all prices | ||
|
ESQ-113-59-L-D
3D CAD
2x13 Positons |
Standard delivery 5 - 7 working days * |
1+: £3.77 | 25+: £3.67 | 50+: £3.47 | View all prices | ||
|
ESQ-120-59-S-D
3D CAD
2x20 positions |
Standard delivery 3 - 5 working days * |
1+: £8.90 | 10+: £8.66 | 25+: £8.20 | View all prices | ||
|
ESQ-128-59-G-D
3D CAD
2x28 positions |
Standard delivery 3 - 5 working days * |
1+: £11.97 | 10+: £11.63 | 25+: £11.02 | View all prices | ||
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
Insulator Material: Black Glass Filled Polyester
Contact Material: Phosphor Bronze
Plating: Au or Sn over 50µ" (1,27µm) Ni
Current Rating (ESQ/TSW): 5.7 A per pin (1 pin powered per row)
Voltage Rating: 550 VAC mated with TSW or ESQ
Operating Temp Range: -55°C to +125°C with Gold -55°C to +105°C with Tin
Contact Resistance: 10 mΩ
Insertion Depth: (3,68mm) .145" to (6,35mm) .250"
Insertion Force: (Single contact only) Standard = 6 oz (1,67 N) avg. ((0,64mm) .025" SQ pin);
Low Insertion Force= 3.3 oz (0,92 N) avg. Normal Force: Standard = 125 grams (4,4 N) Withdrawal Force: (Single contact only) Standard = 5 oz (1,39 N) avg. ((0,64 mm) .025" SQ pin);
Low Insertion Force= 2.9 oz (0,81 N) avg.
Max Cycles: 100 with 10µ" (0,25µm) Au
RoHS Compliant:
Lead-Free Solderable: Wave only
