| Part No. | Stock Qty | 1+ | 100+ | 500+ | 1000+ | Qty |
|---|---|---|---|---|---|---|
|
MB223-500-M10
1x10 positions |
Standard delivery 15 - 17 working days * |
£0.79 | £0.79 | £0.79 | £0.79 | |
|
MB223-500-M11
1x11 position |
Standard delivery 2 - 4 working days * |
£0.90 | £0.90 | £0.90 | £0.90 | |
|
MB223-500-M12
1x12 positions |
Standard delivery 15 - 17 working days * |
£1.02 | £1.02 | £1.02 | £1.02 | |
|
MB223-500-M14
1x14 positions |
Standard delivery 15 - 17 working days * |
£1.11 | £1.11 | £1.11 | £1.11 | |
|
MB223-500-M15
1x15 positions |
Standard delivery 15 - 17 working days * |
£1.20 | £1.20 | £1.20 | £1.20 | |
|
MB223-500-M2
1x2 positions |
10755 in stock | £0.49 | £0.41 | £0.33 | £0.27 | |
|
MB223-500-M3
1x3 positions |
12602 in stock | £0.67 | £0.56 | £0.44 | £0.37 | |
|
MB223-500-M4
1x4 positions |
531 in stock | £0.56 | £0.44 | £0.37 | £0.32 | |
|
MB223-500-M5
1x5 positions |
2361 in stock | £0.70 | £0.56 | £0.47 | £0.40 | |
|
MB223-500-M6
1x6 positions |
Standard delivery 15 - 17 working days * |
£0.48 | £0.48 | £0.48 | £0.48 | |
|
MB223-500-M8
1x8 positions |
Standard delivery 15 - 17 working days * |
£0.64 | £0.64 | £0.64 | £0.64 | |
|
MB223-500-M9
1x9 positions |
Standard delivery 15 - 17 working days * |
£0.71 | £0.71 | £0.71 | £0.71 |
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm pricing and delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
Cage clamp: Brass, Tin plated, 0.7t
Terminal: Brass, Tin plated, 0.7t
Insulating Body:Polyester (UL94V-0)
Screw: M2.6, steel, Chromatized
Color: Grey
Operation temperature: -33 °C to 105 °C
Short-time temperature: up to 250°C ( 482℉)
Current rating: 10 Amp AC300V
Insulation Withstands Volt: AC2000V min
Insulation resistance: >5000MΩ at DC500V
PCB hole Dia.: φ1.4mm
Wire strip length: 4 ~ 5mm
Wire range: 12 ~ 24 AWG
Screw torque: 3.5 lb-inch
