| Part No. | Stock Qty | 1+ | 5+ | Qty |
|---|---|---|---|---|
|
L04a-04-PABB-100F
|
Standard delivery 15 - 17 working days * |
£51.10 | £43.88 | |
|
L04a-06-PABB-100F
|
Standard delivery 15 - 17 working days * |
£49.37 | £41.10 | |
|
L04a-08-PABB-100F
|
Standard delivery 15 - 17 working days * |
£58.00 | £48.95 | |
|
L04a-10-PABB-100F
10 Positions x 100 ft |
5 in stock | £52.46 | £43.20 | |
|
L04a-15-PABB-100F
15 Positions x 100 ft |
4 in stock | £98.95 | £87.12 | |
|
L04a-16-PABB-100F
16 Positions x 100 ft |
Standard delivery 15 - 17 working days * |
£98.46 | £82.03 | |
|
L04a-17-PABB-100F
17 Positions x 100 ft |
Standard delivery 30 - 32 working days * |
£100.61 | £86.66 | |
|
L04a-20-PABB-100F
20 Positions x 100 ft |
3 in stock | £98.76 | £82.70 |
* Delivery times are from point of order and subject to material availability.
* When ordering more than in stock, please contact us to confirm pricing and delivery time
* Need help or more stock/delivery information or volume pricing - Please contact us
UL Style : 2651
Operating Temperature : -20°C to +105°C
Flammability Rating : UL-VW-1
Voltage Rating : 300V Physical
Insulation Material : Polyvinyl Chloride (PVC)
Conductor : #26 AWG Overcoated Stranded Tinned Copper #26 AWG Stranded Tinned Copper
Color : Grey
Impedance : 120Ω (Unbalanced)
Capacitance : 11.2pF/ft.
Inductance : .14 uH/ft.
Propagation Delay : 1.35 ns/ft.
Insulation Resistance : 1GΩ /M min
RoHS Compliant
L04a Ribbon cable is a 2.54mm pitch ribbon cable mated with Toby's A04a series HE14 type sockets creates a standard single row ribbon cable assembly. To mate with C38 or C39 series PCB mount shrouded headers.
